Manson HCS-3202USB Power Supply 1-36V DC / 10 A
Description
Switch mode power supply
Following up on the success of our HCS series high power supplies, we come up with this new range of low power supplies based on the feedbacks from end users. We add an USB port for access to computer to run cyclical operation with programmable voltage, current, period time and cycles. The on-housing presets, separate remote control, rotary encoder dual action control for easy tuning of voltage and current, and all the features of the original HCS are kept. In addition it is of universal AC input voltage . It is probably the most cost effective Remote Programmable Power supply with such advanced features and protections. It is ideal for laboratory, university, work shop, production, quality control and sophisticated DIY applications.
Remote Programmable via USB to computer
20 programmable sets of V, I & cycle periods for repetitive operation up to 999 cycles
3 user defined V & I panel presets for frequent use
Analogue Remote Control of V, I, & output On-Off without computer.
Rotary encoder knob with definitive action of fine and coarse tuning
Smart cooling fan speed control from zero to full speed
Self diagnostic check on LED display and cooling fan on start up
Isolated ground , Active PFC & high power efficiency
Universal AC input
Over load , Tracking Over Voltage Protections
Constant Current limit setting with output open circuit
Type
Switching Mode
Input Voltage
90 - 264VAC 50/60Hz~
Rated output power
360W
Number of output
1
Output Voltage range
1-36VDC
Output Current range
0-10A
Voltage load regulation
=50mV
Current load regulation
=100mA
Voltage line regulation
=20mV
Current line regulation
=50mA
Output ripple and noise
=5mV
Voltage Setting Resolution
100mV
Voltage meter digit and accuracy
3 Digit LED Display ±(0.2% +3counts)
Current Set Resolution
10mA
Current meter digit and accuracy
3 Digit LED Display ±(0.2% +3counts)
Extra output Voltage
N/A
Auto-range (con)
No
Constant Current mode
Yes
Remote programing
Yes
Connection type
USB
Preset program
3 preset
Internal program
No
Commend Set
Manson Standard
Optimal Efficiency
=86%
Cooling Method
Thermostatic Control Fan from Zero to full speed
Protections
Overload, Short Circuit by Constant Current, Output Tracking Over Voltage, Over Temperature
Floating ground
Yes
Approvals
CE EMC: EN 55011, EN 55032 LVD: EN 61010, EN 62368-1
Dimensions (WxHxD)
200x80x208mm
Weight
2.4kg
