Yaesu FT-70DE B2 Dualband Transceiver

Handheld transceiver 144/430MHz analog FM and digital C4FM

· compatible with System Fusion

· Digital function with AMS (Automatic Mode Select)

· sophisticated C4FM digital: Digital Group Monitor (GM), Digital Group Identification DG-ID, Digital Personal Identification PD-ID

· 5 watts of power into a compact laptop

· 700mw of power audio for clear listening

· multi-color modes indicator

· robust IP-54 (dust/water protection)

· 1,105 memory channels

· wide-band reception from 108 to 579,995 MHz

· versatile scanning functions: VFO scan programmed priority channel, memories,

· 1800mAh lithium ion battery included

· external DC power socket and battery charger

· mini-USB-socket for external memory management and software

· radio-radio cloning cable is CT-27 (optional)

· encode/decode CTCSS tones and DCS

· RF Squelch

· functions: Automatic Power Off (APO), Transmitter TimeOut-Timer (TOT), Busy Channel Clock-Out (BCLO) the FT-70D with the AMS function identifies the type of modulation of the received signal, be it digital or analog FM C4FM, and then automatically and instantaneously the receiver to the appropriate modulation. Another feature that distinguishes the new handset is the Digital Group Monitor (GM) with implemented DG-ID (Digital Group Identification) and DP-ID (Digital Personal Identification), which simplify operations at GM. Simply put the transceiver by choosing the same DGID or DP-ID allows you to communicate between radio with the same code, are selectable codes DG-ID and DP-ID from 00 to 99, thus providing a high degree of flexibility so that the user can have Group communications with other amateur radio operators in GM mode according to their individual requirements.

Main technical characteristics:

-Power 5Watt (2/0, 5W) in broadcasting in bands 144-146MHz, 430-440MHz

-Receiving 108-579,995 MHz

-Audio output 700mW (@ 16 O 10% THD, internal speaker)

-Modulation F2D, F3E, F7W

-Dimensions 60 x 98 x 33 mm (Wxhxd) and weighs only 255gr with SBR-engine and antenna
